설명
기본정보
모델 번호. | WNS6-1.25-YQ |
기능 | 증기보일러, 기름보일러 |
연료 | 가스 연소 |
설치 | 포장된 주전자 |
구조 | 포이어로어 |
미디어 | 증기와 물 |
물 순환 | 강제순환 |
드럼 배치 | 수평보일러 |
압력 | 압력 |
제조 수준 | ㅏ |
불타는 스타일 | 챔버 연소 보일러 |
사용 | 산업, 가정, 차량, 발전소 |
운송 패키지 | 플라스틱 랩으로 벗은 상태 |
등록 상표 | 리치-케셀 |
기원 | 중국 |
HS 코드 | 8402190000 |
생산 능력 | 5000톤/년 |
상품 설명
![Automatic Fuel (gas) Steam Boilers](/uploads/p/07a8bf40d43746c5b8fbb0dbd9e2ae07.webp)
![Automatic Fuel (gas) Steam Boilers](/uploads/p/0fb53dc461f8418bbb68595456c89b29.webp)
주요 특징: 1. 오일 보일러는 산업적으로 지능적으로 설계되었으며 세부 사항에 주의를 기울여 고객이 시간과 비용을 절약하는 데 도움이 됩니다. 2. 자체 연구실을 통해 석유보일러의 모든 솔루션은 실험 데이터를 기반으로 합니다. 3. 기름보일러는 안전하고 환경친화적입니다. 친절한 에너지 절약 제품.4. 기름 보일러에 대한 연중무휴 온라인 조언을 제공합니다.5. 석유보일러 업계에서 30년 이상의 경력을 보유하고 있습니다.6. 맞춤형 석유 보일러 솔루션은 귀하의 산업과 사례를 기반으로 합니다.7. 올바른 석유 보일러 솔루션은 장비의 자본 및 운영 비용을 절감할 수 있습니다.
![Automatic Fuel (gas) Steam Boilers](/uploads/p/a53f6d91c0f54c0cae7cfe9f90a3aa89.webp)
모델 번호. | WNS0.5-1.0-Y/Q | WNS0.7-1.0-Y/Q | WNS1.0-1.0 /1,25-Y/Q | WNS1,5-1,0/1,25 -Y/Q | WNS2-1,25/1,6/2,5 -Y/Q | WNS3-1.25/1.6/2.5 -Y/Q | WNS4-1,25/1,6/2,5 -Y/Q | WNS5-1.25/1.6/2.5 -Y/Q |
정격 증발 (t/h) | 0,5 | 0,7 | 1 | 1.5 | 2 | 삼 | 4 | 6 |
정격 압력 (MPa) | 1,0 | 1,0 | 1,0/1,25 | 1,0/1,25 | 1,25/1,6/2,5 | 1,25/1,6/2,5 | 1,25/1,6/2,5 | 1,25/1,6/2,5 |
Nenndampftemperatur. (℃) | 184 | 184 | 184/194 | 184/194 | 194/205/220 | 194/205/220 | 194/205/220 | 194/205/220 |
능률 | 93% | 93% | 93% | 93% | 93% | 93% | | |
| | | | | | | | |
| | | | | | | | |
| | | | | | | | |
| | | | | | | | |
| | | | | | | | |
| | | | | | |
![Automatic Fuel (gas) Steam Boilers](/uploads/p/8b3790100bc14cf98ac66d61289231ab.webp)
![Automatic Fuel (gas) Steam Boilers](/uploads/p/9cf4d01cdda64ad18f90b708a24bc297.webp)
Henan Reach Special Equipment is located in the central city of Zhengzhou, Henan Province, China. Our company is a professional trade supplier of industrial equipment such as boilers, with 12 production companies with various qualifications and over 30 employees. Mainly engaged in the design and sales of oil and gas steam boilers, coal/biomass steam boilers, oil and gas thermal oil boilers, coal/biomass thermal oil boilers, electric heating steam boilers, oil and gas hot water boilers, and medium and high temperature hot air furnaces. The manufacturers our company collaborates with are all legitimate production enterprises with A-level and B-level qualifications for Chinese boiler manufacturing. They have various certifications both domestically and internationally, including CE certification, ASME certification, etc., which can fully meet the matching requirements for boilers in various production environments in different countries. The factories our company collaborates with are all based on the manufacturing and production of various pressure vessels such as steam boilers, thermal oil boilers, and autoclaves. We have established an industrial system that integrates product development, engineering project design, equipment manufacturing, engineering installation, system debugging, pre-sales, sales, and after-sales services. Our company's products are not only sold and widely praised in the domestic market of China, but also exported to more than 60 countries and regions such as South Korea, Vietnam, Myanmar, Mongolia, the Philippines, and Indonesia, receiving recognition and pursuit from customers. I believe that our company can bring objective benefits to customers with advanced technology, excellent equipment, excellent products, and exquisite services. We look forward to long-term friendly cooperation with friends from various countries! Welcome to our store!Q1: What about after sales service, such as installation and commissioning?Answer:(1)English manual, drawings are supplied with boiler. (2)Engineers are able to instruct installing and commissioning abroad.Q2: What are the main products?Answer:(1)Oil fired steam boiler, capacity from 0.1t-20t (2) Gas fired steam boiler, capacity from 0.1-20t (3) Electric steam generator, capacity from 36kw-28800kwQ3: How to insure your product quality?Answer:(1)Strength calculation report with applied materials information; (2)100%NDT(non-destructive inspection) report of steel plate, tube and welding rod; (3)100% X-ray inspection(welding seam): ensure the quality of entire boiler; (4)Hydrostatic test: ensure the standard working pressure and safety; (5)Third-party inspection report; (6)Passed ISO, ASME certifications
